Description
YONGLI A4s,100w co2 laser,for laser engraving machine
Product Description
|
Code
|
A0s
|
A1s
|
A2s
|
A4s
|
A6s
|
A8s
|
|
Length (mm)
|
600
|
1100
|
1250
|
1450
|
1650
|
1850
|
|
Diameter (mm)
|
80±2
|
80±2
|
80±2
|
80±2
|
80±2
|
80±2
|
|
Rated Power (watts)
|
28
|
70
|
90
|
100
|
130
|
150
|
|
Max Power (watts)
|
35
|
90
|
100
|
130
|
160
|
180
|
|
Ignition Voltage (kV)
|
12
|
20
|
25
|
28
|
30
|
34
|
|
Working Voltage (kV)
|
8
|
15
|
18
|
19
|
21
|
22
|
|
Working Current (mA)
|
20
|
22
|
26
|
28
|
30
|
35
|
|
Recomended Working Current (mA)
|
16
|
18
|
21
|
22
|
24
|
28
|
|
Power Instability(%)
|
≤±5
|
≤±5
|
≤±5
|
≤±5
|
≤±5
|
≤±5
|
|
Warranty (months)
|
6
|
10
|
12
|
12
|
12
|
12
|
|
Reference Suggesting Table
|
||||||||||||||
|
Code
|
Power
(w)
|
Acrylic
(mm)
|
Leather(mm)
|
Plywood
|
MDF
|
Stainless Steel
|
Carbon Steel
|
|||||||
|
A2s
|
80
|
＜10mm
|
＜2mm
|
Gift
|
＜5mm
|
—
|
—
|
|||||||
|
A4s
|
100
|
＜10mm
|
＜2mm
|
Gift
|
＜8mm
|
—
|
—
|
|||||||
|
A6s
|
130
|
＜15mm
|
＜2mm
|
X
|
X
|
—
|
—
|
|||||||
|
A8s
|
150
|
＜20mm
|
＜2mm
|
X
|
X
|
＜1.5mm
|
＜1.5mm
|
|||||||
|
Note:X stands for this tube is capble of cutting this material,but it is not recomended,because of pollution and low requirement for beam spot meanwhile high cost.
|
||||||||||||||
