Description
- Brand Name: YunlinLi
- Certification: CE
- Origin: CN(Origin)
- Size: 500 * 350 * 190 mm
- Model Number: 721
- Focal Length: /
- Weight: 9
- Wavelength Range: 330 – 1020 nm
- Type: Single Beam Spectrometers
- Measurement Range: 330 – 1020 nm
Features:
● With backlit LCD display, the reading is clear and clear.
● The advanced holographic blazed grating C-T monochromator has the advantages of high wavelength accuracy, good monochromaticity and low stray light.
● Using microcomputer measurement system, T-A conversion accuracy is high, and there are automatic adjustment of 0% (T) and 100% (T), direct density reading, concentration factor setting, and serial data printer can be selected for data printing.
● The measurement reading has high accuracy, good repeatability and stability.
Specifications:
Wavelength range: 330 nm – 1020 nm
Maximum allowable wavelength error: ± 2 nm
Wavelength repeatability: ≤1 nm
Maximum allowable error of transmittance: ± 0.6% (T)
Transmittance repeatability: ≤0.2% (T)
Spectral bandwidth: 4 nm
Stray light: ≤0.2% (T)
Instrument size: 500mm × 350mm × 190mm
Power supply voltage: AC220V/ AC110V
