UV 3watt 5watt laser marking machine engraving glass

$3,950.00

SKU: 3466071018651 Category:

Description

Youtube link: https://youtu.be/jWWsZSGQPto

UV 3watt 5watt laser marking machine engraving glass

Product Description

UV laser marking 1-1.jpg

>>>    Product Introduction     <<<

UV Laser Marking Machine 3 Watt 5 Watt For Code Glass Plastic HDPE belongs to the series of laser marking machine, but its use of 355nm wavelength. It has small focus light spot, reduce material mechanical deformation. High peak power, small pulse width, small thermal effects of processing. It can do ultra-fine marking on special materials.



If you have the high requirement for the marking effect, BEC UV laser marking machine is the best choice.





Features:

  • Small beam diameter and fine marking line
  • Good quality and high laser beam stability
  • Complete machine stability, simple and easy operation
  • Narrow pulse width, small heat affected zone, workpiece without damage
  • Suitable for sensitive material as cold light source
  • Suitable for sensitive material as cold light source

Advantages:



• Hyper-fine Laser marking base on Imported UV Laser marking machine’s good light beam quality and small focusing spot.
• Good processing effect and wide applicable material type base on mild heat-affected of UV Laser marking.
• High processing accuracy, high marking speed and good stability base on imported high-speed galvanometer.
• Convenient Operation: Convenient data processing with dedicated laser marking software. Interface is simple and friendly, easy operation.

• Available support file format:  PLT, DXF, AI, SDT, BMP, JPG, JPEG,TGA, PNG, TIF, TIFF, etc.

 Support one-dimensional code and two-dimensional code marking such as Code39, EAN, PDF417, DATAMATRIX, etc.

• Option function: marking-on-the-fling, rotary marking and X,Y 2D platform.



>>>    Technical Parameters     <<<

Product Name UV Laser Marking Machine 3 Watt 5 Watt For Code Glass Plastic HDPE
Model BEC-UV3J BEC-UV5J
Laser Power 3W 5W
Wavelength 355nm
Pulse Width <15ns@30kHz <15ns@40kHz
Frequency Range 20KHz-150KHz
Beam Quality M2 ≤1.2
Beam Diameter Non-expanded: 0.7±0.1mm Beam expansion: 7.0±1.0mm
Product Line Speed The encoder measures speed, it can be adjusted according to the line speed.
Marking Speed 800 standard characters /s 1000 standard characters /s
Cooling Mode Water cooling
Enviornment Temperature 15℃~35℃ ( No condensation )
Power Supply 220V( 110V ) 50Hz/60Hz
Optional Parts 2D/3D working table, rotary fixture, conveyor belt, fume exhaust, etc.

uv laser marking 4-2.jpg

Detailed Images

>>>    Machine Structures     <<<

UV laser marker 3.jpguv laser marking 4-1.jpg

>>>    Machine Details     <<<

UV laser marker 6.jpg

>>>    Applications     <<<

    *    It is widely used in electronic components, battery chargers, electric wire, computer accessories, mobile phone

         accessories (mobile phone screen, LCD screen) and communication products.

    *   Automobile and motorcycle spare parts, auto glass, instrument appliance, optical device, aerospace, military

         industry products, hardware machinery, tools, measuring tools, cutting tools, sanitary ware.

    *   Pharmaceutical, food, beverage and cosmetics industry.

    *   Glass, crystal products, arts and crafts of surface and internal thin film etching, ceramic cutting or engraving, clocks

        and watches and glasses.

    *  It can be marked on polymer material, majority of the metal and non-metallic materials for surface processing

       and coating film processing, pervious to light polymer materials, plastic, fire prevention materials etc..

uv laser marking 5-1.jpg

3W 5W split uv laser marking machine marker glass with laptop

Additional information

Model Number

Rotary fixture, BEC-UV5, BEC-UV3

Power

3W/5W
