Spectroradiometer Price Integrating Sphere Spectrometer OHSP350M HOPOO

$3,120.00

SKU: 3528310018651 Category:

Description

Product Description

OHSP350M Spectroradiometer


OHSP-350M Luminous flux Version

Measuring Parameters

Meas parameters Wave range:350-950nm
1. CCT Tc (K) and Blackbody deviation Duv
2. light illumination E (LX), candlelight E (Fc) Spectral irradiance Ee (W/m2)
3. chromaticity coordinates (x, y), (U, V), (U ‘, V’)
4. relative spectral power distribution P (lambda)
5. color index Ra, Ri (i=1 ~ 15)
6. color tolerance SDCM
7. Dominant wavelengths, peak wavelengths
8. Visual ratio of light and shade S/P
9. color purity, red ratio, green ratio, blue ratio, CIE1931 three basic color stimulus value X, Y, Z
10. PAR ,PPFD, YPFD,PPF, radiation of Eb Ey Er Erb Ep, Kppfv
11. light source flicker frequency Hz, modulation depth, flicker percentage, flicker index, risk hints
12., Blu ray hazard weighted irradiance (mW/m2), Blu ray irradiance ratio (mW/lm), safe and allowed time of irradiation (S),
hazard level
13. Rf, Rg (TM-30 chromaticity parameters)
14.Luminous flux (LM), radiation flux (W) and light effect (lm/W)

Model
OHSP-350M Spectrometer(Luminous flux)
Wavelength range
350nm~950nm
Split model
Asymmetrical CT splitting system for long focal cross
Sensor
High precisionCCD
Optical device
Optical fibre + integrator
Spectral bandwidth

(FWHM)
2nm
Spectral resolution
0.2nm
Wavelength accuracy
±0.5nm
Accuracy
1 class(±4% degree±1 degree)
Chromaticity coordinates accuracy
±0.0025
Stray light
≤0.3%
Color temperature range
1,000K~100,000K
Luminous flux range
Depends on sphere size
Integral Time
50µs~10000ms
Interface
Micro USB、MD8
Using T/H range
(-10~40)℃,H<70%(non-condensing)
Store T/H range
(-20~45)℃,H<70%(non-condensing)
Screen Size
5.0″IPS HDLCD touch screen
Communication
PC:USB、485
Storage
8GTF(Micro SD)
Power Supply
Built-in lithium battery
Continuous
One charge for 20 hours
Size/weight
138.5×81×23mm/430g

Application

Additional information

Measurement Range

350-950nm
