Description
Product Paramenters
Output Power
|
300W
|
500W
|
1000W
|
||
Wavelength
|
808nm(800-810nm)
|
||||
Number of bars
|
1-20Pcs
|
||||
Solder type
|
Hard solder or soft solder
|
||||
Typical Pulse Width
|
10ms~200ms
|
||||
Repetition Rate
|
0~10Hz
|
||||
Max Duty Circle
|
20%
|
||||
Operation Current
|
40A
|
40A
|
40A
|
||
Operation Voltage
|
<12V
|
<20V
|
<40V
|
||
Cooling Requirement
|
1. Flow Rate: >4.5L/min
|
||||
2. Water quality: Industrial grade, anti-freeze possible, particle filter<100µm
|
|||||
3. Chiller water Temperature: 15°C-25°C.
|
Product Description
MA Diode Laser Stack Product Outline
Macro channel laser diode stacks are good for both quality and price. The structure of packaging is flexible and it has no special need for water. Oriental-laser have studied the laser diode stacks for 5 years. We deliberate on diode laser packaging and the design of laser stack. Finally we find the method to overcome macro channel laser diode stacks’ chip burning and we developed the high reliability laser diode stacks for hair removal.
MA Diode Laser Stack Working Principle
The process of diode laser’s working is the change from electric energy to light and heat energy.When the chip which is inside the macro channel is working, the cooling water flow inside the laser stack and bring the extra heat and make sure the chip going well.
Our Advantages
We can repair variety brand diode laser stack and lase handle
This diode stack is Alma Soprano 12 bar black side plate & right-angled electrode diode stack.It is used for Alma Soprano handle piece repairing and replacement.Oriental-laser ed on diode laser bar assembling for more than 16 years and we have seen various alma soprano diode laser stacks.Also we can use the same Jenoptik bar like Alma used to recondition the power the laser soprano power.
