GH04850B2G 487 nm 50 mW Cyan Laser Diode

GH04850B2G Laser Diode is a 50 mW cyan laser diode with a typical wavelength of 487nm.

Design Wavelength
487 nm
Operating Current Typ [mA]
105 mA
Operating Temp. Range
-10 to 60 °C
Operating Voltage
6 V
Package
TO-18
Threshold Current
40 mA
Storage Temperature Range
-40 to 85 °C
Optical Power @ 25°C
50 mW

About the GH04850B2G 487nm 50 mW Cyan Laser Diode
This is a GH04850B2G 50 mW cyan single-mode laser diode with a wavelength of 487 nm. It is manufactured by Sharp.
