Color sensors S11059-02DT/-03DS I2C int erface-compatible color sensor The S11 059-02DT/-03DS is a digital color senso r that supports the I2C (inter-integrat ed circuit) interface.
It is sensitive to red (λ=615 nm), green (λ=530 nm), blue (λ=460 nm), and infrared (λ=855 nm) light, and outputs detected results as 16bit digital data for each color.
The photodiode for each color is automa tically switched sequentially to perfor m measurements.
The sensitivity and int egration time can be adjusted so that l ight measurements can be performed over a wide range.
Features I2C interface compatible Sequent .

I2C interface compatible
Sequential measurements of red, green, blue, and infrared light
2-step sensitivity switching (sensitivity ratio 1 : 10)
Sensitivity adjustment by setting the integration time
Low voltage (2.5 V or 3.3 V) operation
Low current consumption: 75 μA typ.
With internal infrared-cut fi lter
LCD backlight adjustment for cell phones, notebook PC, etc.
Energy-saving sensor for large-size TV, etc.
Various types of light detection or color adjustment
Absolute maximum ratings
Parameter Symbol Condition Value Unit
Supply voltage Vdd Ta=25 °C -0.3 to +6 V
Output current Io Ta=25 °C ±10 mA
Power dissipation P Ta=25 °C 300 mW
Operating temperature Topr No dew condensation*1 -25 to +80 °C
Storage temperature Tstg No dew condensation*1 -40 to +85 °C
Reflow soldering conditions*2 Tsol Peak temperature 240 °C max., 1 time (see page 10) –
*1: When there is a temperature difference between a product and the surrounding area in high humidity environment, dew
condensation may occur on the product surface. Dew condensation on the product may cause deterioration in characteristics and
reliability.
*2: Moisture absorption and refl ow conditions: JEDEC J-STD-020D LEVEL5a
Note: Exceeding the absolute maximum ratings even momentarily may cause a drop in product quality. Always be sure to use the
product within the absolute maximum ratings.
Wide dynamic range (Low gain: 1 to 10 klx)
Standard packing state
S11059-02DT: reel
S11059-03DS: stick
