Raycus High power pulsed laser source for Laser marking Machine

$1,274.00$2,294.50

SKU: 3468033018651 Category:

Description

Products Description

With high average power, high single pulse energy, square or round homogenized spot output, convenient use and maintenance, etc., it is an ideal choice for mold surface treatment, automobile manufacturing, shipbuilding, petrochemical industry, rubber tire manufacturing and other industrial applications .

Product Paramenters

Model
RFL-P20QE
RFL-P20QS
RFL-P30Q
RFL-P50QB
RFL-P100Q
Rated output power: (W)
20
20
30
50
100
Center wavelength: (nm)
1064±5
1064±5
1064±5
1064±5
1064±5
Repetition frequency range (kHz)
30-60
30-60
40-60
50-100
20-200
Output power stability
<3%
<3%
<3%
<3%
<5%
Pulse width range (ns)
120-150
120-150
130-160
120-150
50-110
Output spot diameter (mm)
7±1
7±1
7±1
7±1
6.5±1
Beam quality M²
<1.5
<1.5
<1.6
<1.6
<1.6
Maximum single pulse energy (mJ)
0.67
0.67
0.75
1
1
Output fiber length (m)
3 (can be customized)
3 (can be customized)
3 (can be customized)
3 (can be customized)
3 (can be customized)
Input power (VAC)
24
24
24
24
24
Power adjustment range (%)
10-100
10-100
10-100
10-100
10-100
Power consumption (W)
170
180
250
500
1000
Dimensions (mm)
260*340*120
215*290*95
215*290*95
260*340*120
360*390*123
cooling method
Air-cooled
Air-cooled
Air-cooled
Air-cooled
Air-cooled

Applications

laser marking

laser welding

laser cleaning

Our Advantages

Our company is located in Wuhan Optics Valley and has more than 20 years of laser industry experience

Laser Technology R&D Laboratory

Large inventory of lasers

Additional information

Model Number

RFL-P50QB, RFL-P30QB, RFL-P20QB, RFL-P30QS, RFL-P20QS, RFL-P20QE, RFL-P30Q
