Portable Type 20w 30w 50w Fiber Laser Marking Machine

$2,618.99

SKU: 3356017012971 Category:

Description

Portable Type 20w 30w 50w Fiber CO2 Laser Marking Machine

Product Description



1.Reci glass laser tube and high-speed galvanometer.

2. High precision and extremely fast speed. Marking depth is controllable optionally.



3.Wide application. It can mark most non-metals.



4.The marking lines are clear, it can withstands heavy wearing.



5. The optical system is fully sealed, it can prevent the dust enters laser body and reduces the equipment failure rate.



6.Chinese and English software are optional. The software works in Windows environment and it is compatible with many file formats, for instance, PLT, PCW, DXF, BMP and others saved by CORELDRAW, AUTOCAD, PHOTOSHOP and other software. Meanwhile, SHX and TTF can be imported into the software directly.



1








Technical parameters



Model

MK-20M

Fiber Laser type

Co2 Laser

Max single pulse energy

1.0MJ

Pulse duration

6-250ns

Laser beam quality M2

<1.2

Frequency

2–60kz

Wave length

10.6um

Marking area

110*110mm(optional)

Marking depth

0.01-0.08mm

Max position speedy

8000mm/s

Control program

Genuine EZCAD control system Compatible with win7/8/10

Graphic format supported

Jpg,Bmp, Dxf, plt

Working voltage

AC220V 50HZ/ AC110V 60HZ

Cooling type

Air cooling/Water cooling

Operating parameter

0-40

Packing size

90*50*80cm

Gross weight

About 95kgs

Part of the machine:



1. co2 laser  High quality SYNRAD BRAND metal laser tube importable from USA



2.  Mainboard (Add anti-static device)

100% Genuine EZCAD board Quality Genuine

EZCAD control board andprogram(BJJCZ

brand) which support XPWIN7 /8 /10 32/64

bit operating system.



3. Galvanometer

Best quality co2 digital Galvotech scan head



4.Quality Wavelength optical lens

we have optional size:110*110mm,150*150mm,175*175mm,200*200mm,300*300mm etc.



0 (4)0 (3)



0 (1)0

Marking sample

 laser marking machine (3)



  03

Additional information

Model Number

MK-20M

Power

20W, 30W, 50W
