Portable Colorimeter and Color Difference Meter

  • Home
  • Portable Colorimeter and Color Difference Meter
Sale!

Portable Colorimeter and Color Difference Meter

$454.30

997 in stock

SKU: 1925421747 Category:

Description

  • Measurement Range: L: 0to 100
  • Weight: 700g
  • Brand Name: DANSTLEE
  • Model Number: WR10
  • Focal Length: 40mm
  • Wavelength Range: 400nm-700nm
  • Type: Split Beam Spectrometers
  • Size: 199x68x90mm
  • Model Number: WR10
  • Measuring Caliber: Diameter 8mm
  • Display Mode: CIELAB
  • Measurement Range: L: 0to 100
  • Language Patterns: English/ Simplified Chinese
  • Repeated Accuracy: E<0.08
  • Measurement Interval: 1 Sec.
  • Light Source: D65
  • Storage Capacity: 100 standard samples and 1000 test sample
  • Dimension : 199x68x90mm

 Portable Colorimeter and Color Difference Meter













WR10 8mm  portable digital  Colorimeter, color meter ,color analyzer



Description:



 Portable Colorimeter WR10 developed according to the measuring requirements on different products and gain many optimal achievements with high cost performance.
The most convenient colorimeter: automatic correction when starting up (national patent)
Environmental, low energy consumption instrument, high capacity lithium battery
Comfortable observation with real color screen display
Exquisite and delicate









WR10  Portable Colorimeter

Model Number

WR10

Display mode

 CIELAB,

Color difference formula

ΔE *ab

Illumination Condition

 CIE Recommendation:8/d

Light Source

D65

Sensor

Photodiode array

Measuring Aperture

Φ8mm

Measuring Condition

 Observer:CIE 10° Standard observer

Measuring Range

L:0-100

Repeated Accuracy

 ΔE<0.08

Table Difference

 ΔE <0.2

Measurement Time

1 second

Storage Capacity

100 standard samples and10000 test sample

Battery Power supply

Li-ion battery, 5000 times Measurement

Lifetime of Bulb

5years more than 160 million measuring

Display screen

TFT true color 2.8inch@(16:9)

Interface of External

USB2.0 (USB-B)

RS-232 (115200bps)

Working Temperature Range

0°C-40°C (32°F-104°F)

Storage Temperature Range

-20°C-50°C (-4°F-122°F)

Humidity Range

 Relative humidity less than 85%,without condensation

Net Weight

700g

Dimension

199x68x90mm

Demension after package

400x240x340mm

Standard Accessory

AC adapter/ 3000mAH Li-ion battery

Optional Accessory

 Flour measuring device/Micro printer





Feature:



1.Through the SCM test

2.Simple, accurate, easy-to-use, convenient

3. Design in line with industry norms, good feel, easy to grasp, Steady body.

4. Clear and bright screen, large font display, intuitive chromaticity diagram,

color difference bias figure shows color simulation.

5. Advanced Power Management



Application :The colorimeter is applicable in textile, printing and dyeing, clothing, footwear, leather, chemicals, plastics, plastics, pigments, paints, inks, printing, metal, photography, toys, and other industry color quality control, color control, color analysis, sampletesting, production line testing, also suitable for injection molding, ink, paint, spray and other auxiliary color
