Portable 2418 Pro 3 Axis Mini DIY CNC Router Adjustable Speed Spindle Motor Wood Laser Engraving Machine Milling Engraver

  • Home
  • Portable 2418 Pro 3 Axis Mini DIY CNC Router Adjustable Speed Spindle Motor Wood Laser Engraving Machine Milling Engraver

Portable 2418 Pro 3 Axis Mini DIY CNC Router Adjustable Speed Spindle Motor Wood Laser Engraving Machine Milling Engraver

$521.85

999 in stock

SKU: 1005002649828911 Category:

Description

  • Origin: CN(Origin)
  • Certification: NONE
  • Condition: New
  • Model Number: CNC2418 Upgrade Version (Without Laser Module)
  • CNC or Not: CNC
  • Is Smart Device: No
  • Frame Material: Aluminum Alloy, Bakelite
  • Color: Black
  • Control Software for Spindle: GrblControl
  • Control Software for Laser: Litefire
  • Adapter Input Voltage: AC 110-240V 50/60Hz
  • Adapter Output Voltage: DC 24V 4A
  • Working Area: Approx. 240x180x40mm
  • Product Weight: 6 kg

Specification:

General Specification
Model CNC2418 Upgrade Version (Without Laser Module)
Frame Material Aluminum Alloy, Bakelite
Color Black
Working Area Approx. 240*180*40mm
Product Weight 6 kg
Control Software for Spindle GrblControl
Control Software for Laser Litefire
System Requirements Windows XP , Win7, Win8, Win10.
Adapter Plug 2-Pin US Plug
Adapter Input Voltage AC 110-240V 50/60Hz
Adapter Output Voltage DC 24V 4A
Features 1. Aluminum Profile Stable Construction
2. 3 A xis Movable, Adjustable Speed Spindle Motor
3. Contains Quickstart Guide of GRBL Software
4. 300 x 180 x 40mm Working Area, Meet Most Amateur DIY Needs
5. Engrave Wood, Plastic, Acrylic, PCB, or Similar Material
Can Not Engrave Metal, Steel, Aluminum.
Technical Parameters
Working Voltage DC 24V
Interface USB
Stepper Motor 42 Stepper Motor, Voltage: 12V, Phase Current 1.3A, Torque 0.25N.m
Spindle Motor 775 Spindle Motor (12-36V) 24V: 10000r/min,36V: 12000r/min

Features:

– Assembly requires a certain mechanical skill. All assembly components are included.

– Engraving Materials: The machine can carve wood, plastic, acrylic, PCB, or the like materials.

– Can Not Engrave: Hard metal (such as brass, steel, iron, etc), jade and other very hard texture items.

Note:

1. Instructions & Software: Assembly instructions, control software and further information please CLICK HERE

2. This item contains the spindle motor, but no laser module. If you want to use laser for engraving, you can buy it additionally. Thanks for your understanding, and please note that the input interface (Should be XH2.54-3P or XH2.54-2P) and input voltage (Should be DC 12V) of the laser module should be compatible with the control board on 3018. Besides, the original motor holder is round, please make sure the shape of your laser module is suitable for installation.

Package Included:

1 x Wood Engraving Machine Full Set (Unassembled Delivery)

(Comes with plug adapter according to your country)
(Spindle Motor, Control Board, Z A xis Set, Stepper Motors, and other Assemble Parts are all included.)
