OHSP250 PRODUCTION LINE 485 COMMUNICATION (INDUSTRIAL VERSION) Micro-Spectrometer Radiation Tester

$845.00$3,900.00

SKU: 3528293018651 Category:

Description

Product Description

 .jpg





Products Show

OHSP250 micro-spectrometer : The integra-tion of micro-spectrometer technology and micro-computer technology has transferred the huge measuring instrument in the laboratory to the production line, realized on-line analysis of light and color para-meters, directly output test results through RS485 or USB interface, open communication protocol, and conformed to Modbus commun-ication protocol.




Technical indiactors

Parameters

Specifications

Spectral range

380-780nm

pectral resolution

0.2nm

integration time

10us-10s

detector

TCD1304DG,3648

Standard slit

100um

Grating marking

600l/mm

Focal Length (Input)

45mm

Focal Length (Output)

65mm

transform

16bit/250ksps

Meas Parameters

Parameters

Parameters

CCT(K)

Illuminance E(lx)

Coordinate x,y

CRI Ra

Coordinate u,v

R1-15

Coordinate u’,v’

SDCM

Peak wave(nm)

Centroid wave(nm)

Half width(nm)

Irradiance Ee(W/m2)

Central wave(nm)

Duv

Purity(%)

S/P

Dominant wave(nm)

Spectral distributor

Models

Model

Functional version

Wave Range

Function Description

OHSP250



380-780nm

Base +USB interface

OHSP250P

Plant Light

350-800nm

Base+plant light parameters

OHSP250S

Flagship

350-950nm

Base+plant light+TM-30

OHSP250L

luminance

380-780nm

(cd/m2)

OHSP250I

Industry

380-780nm

IO Control, RS485

OHSP250UV

UV

230-850nm

Base+UV parameters

OHSP250SF

Full function

350-950nm

Base+plant light+TM-30+flicker+blue light



 TEST INTERFACE


Additional information

Usage

OHSP350C, OHSP660T, OHSP250I
