OEM CW Laser Module High Power 12W RGB Diode Laser Modules with AC 90-280V Power Adapter for Professional ILDA Laser Show

$11,640.00

SKU: 33018359905 Category:

Description

  • Item Type: Stage Lighting Effect
  • Style: DMX Stage Light
  • Occasion: Professional Stage & DJ
  • Model Number: LM12WRGB
  • Power: 100W
  • Voltage: 90-240V
  • Brand Name: DYUE
  • Laser Name: 12W RGB Laser Module
  • Color: RGB Color
  • Guaranteed power: 12W
  • Power Red: more than 3.4 W / 635 nm
  • Power Green: more than 2.5 W / 520 nm
  • Power Blue: more than 6 W / 447 nm
  • Beam Specifications: ca. 6 mm / 2 mrad
  • Laser Sources: Diode, DPSS Laser
  • Laser Class: 4
  • Power supply: 85V – 250V AC
  • CW Laser: ILDA Laser Show

OEM CW Laser Module High Power 12W RGB Laser ModulesFor Laser Show

Color diode laser at 635,520,447nm is made features of long lifetime,low cost and easy operating, which is widely used in ILDA laser show

Wavelength: 635/520/447nm ( error range 5mm)

Operating mode: CW

Output power:12W

Ratio power: Red laser more than 3.4W, Green laser more than 2.5W, Blue laser more than 6W

Power stability: less than 1%, less than 3%, less than 5% (rms, over 4 hours)

Beam diameter: 6X6, 3.5X5, 3.2X3.2 (mm, at the aperture)

Beam divergence: 1.9X2.3, less than 1.4X0.8, less than 1.4X0.2 (full angle, mrad)

Polarization direction: Horizontal + Vertical

Warm-up time: less than 5 minutes

Beam height from base plate: 30mm

Operating temperature: 25 degrees celsius (error range 3)

Power supply: 100-240V AC (12V 20A)

Modulaton option: TTL / Analog

Expected liftetime: 10000 hours

Warranty: 1 year
