MLX90614-DCI non-contact infrared temperature sensor module iic interface Provide code, 51 single chip reference code ————————————————– ——– D —- 3V medical application accuracy C –—temperature gradient compensation* I –—- 3° FOV (angle) ———————————————– Module model: GY-906-DCI Using the chip: MLX90614-DCI Power supply: 3-5v (internal low dropout voltage regulation) Communication method: standard IIC communication protocol High quality immersion gold pcb, Size: 11.5*16.5mm Features and benefits: * Small size and low cost * Easy to integrate * Factory calibration settings over a wide temperature range: Sensor temperature range -40…+125 °C Object temperature range -70…+280 °C *Ta and To from 0 to +50 ° C temperature range, the accuracy can reach 0.5 ° C *(medical) high precision calibration *Measurement resolution up to 0.02 °C *Single and dual view versions *Compatible with SMBus digital interface *Customized PWM continuous reading output *3V and 5V supply voltage *The power supply voltage can be adjusted from 8…16V *Energy saving mode *Multiple packaging methods and measurement methods for different application areas *Car level standard Applications: *High precision contactless measurement * Temperature comfort sensor for automotive air conditioning control system *Air conditioning temperature sensing components for residential, commercial and industrial buildings * Windshield anti-fog application *Car view dead angle detection *Industrial mobile component temperature control *Printer, copier temperature control *Home appliance temperature control *health care * livestock monitoring *Moving object detection *Multi-zone temperature control – Two-wire communication supports up to 100 sensors *thermal relay / alarm * Body temperature measurement
