Description
Product Description
Model
|
MFSC 1000
|
MFSC 1500
|
MFSC 2000
|
MFSC 3000
|
|||||
Output Power(W)
|
1000
|
1500
|
2000
|
3000
|
|||||
Central Wavelength(nm)
|
1080±3
|
||||||||
Operation Mode
|
CW/Modulate
|
||||||||
Max. Modulation Frequence(kHz)
|
50
|
20
|
|||||||
Power Instability(%)
|
<3
|
||||||||
Red Laser
|
Yes
|
||||||||
Beam Delivery Optics
|
QBH
|
||||||||
Output Fiber Diameter(μm)
|
20
|
50
|
100
|
||||||
BPP(mm*mrad)
|
<0.41
|
<1.1
|
<3.4
|
||||||
Output Fiber Diameter(m)
|
15(Customizable)
|
||||||||
Operation Voltage(VAC)
|
220
|
380
|
|||||||
Power Consumption(W)
|
4000
|
6000
|
8000
|
12000
|
16000
|
||||
Control Mode
|
Ext. RS232 /Ext. AD /Hyper Terminal
|
||||||||
Power Range(%)
|
10~100
|
||||||||
Ambient Temperature(℃)
|
5~40
|
||||||||
Ambient Humidity(%)
|
<70
|
||||||||
QBH Cooling Water Temperature(℃)
|
Room Temperature
|
||||||||
QBH Cooling Water Flow(L/min)
|
1.5~2.5
|
||||||||
Cooling Water Temperature(℃)
|
25
|
||||||||
Cooling Water Flow(L/min)
|
>12
|
>15
|
>25
|
>30
|
>40
|
