Description
- Brand Name: BJGL
- Origin: Mainland China
- Certification: CE
- Operation Method: macro channel
- Fast Axis Divergence Angle: <31 dgree
- Slow Axis Divergence Angle: <8 degree
- Max. Duty Cycle: 40%
- Max. Pulse Width: 400ms
- Total Bar Quantity: 4/5/6/10 pieces
- Bar Distance: 2.0mm
- Each Bar Power: 50W
- Total Output Power: 200W/250W/300W/500W
- Drift Coefficients: 0.28nm/oC
- Light Beam Spot Size: 10*8/10*10/10*12/10*20
- Threshold Current: 12A
- Operating Current: 40~50A
- Max.Working Voltage: 1.9V/Bar
- Repetition Frequency: 1~10Hz
- Cooling Method: flowing water
- Water Flow Value: >3.0L/minute
- Water Pressure: 0.4~0.6Mpa
