Product Description
It has the advantages of high electro-optical conversion efficiency, good beam quality, high energy density, wide modulation frequency, strong reliability, long life, and maintenance-free operation. It can be widely used in welding, precision cutting, cladding, surface treatment, 3D printing and other fields. Its optical fiber output characteristics make it easier to integrate with robots into flexible manufacturing equipment to meet the needs of three-dimensional processing.
Main Features 1. Excellent beam quality 2.High quality fiber output 3.High Power Stability 4.Continuously tunable output power, quick switching response 5.Maintenance free operation 6.High wall plug efficiency 7.Convenient control interface 8.High frequency modulation
Applications 1.Cutting, Welding 2.3D Printing 3.Scientific research
Specification
|
Model
|
RFL-C1000H
|
|
|
Optical Properties
|
||
|
Average Output Power(W)
|
1000
|
|
|
Operation Mode
|
CW/Modulate
|
|
|
Polarization direction
|
Random
|
|
|
Power Adjusting Range(%)
|
10~100
|
|
|
Central Wavelength(nm)
|
1080±5
|
|
|
Output Power unStability(%)
|
±1.5
|
|
|
Modulation Frequency(Hz)
|
50~20,000
|
|
|
Red Light Indicated Power (mW)
|
0.1~1
|
|
|
IQB optical output characteristics
|
|
|
|
BPP (mm.mrad)
|
<1.5
|
|
|
Beam Divergence(rad)
|
≤0.06
|
|
|
Fiber core(um)
|
50 (100/200 Optional)
|
|
|
Delivery Cable Length(m)
|
10
|
|
|
Electrical Characteristics
|
|
|
|
Operation Voltage(VAC)
|
220±10%VAC,50/60Hz
|
|
|
Control Method
|
RS-232/AD/Ethernet
|
|
|
Other Characteristics
|
|
|
|
Dimensions(mm) width*height *depth
|
410x405x150(Handle Included)
|
|
|
Weight(kg)
|
<25
|
|
|
Cooling
|
Water cooling
|
|
|
Operating Temperature(℃)
|
10-40
|
|
