KINDLELASER CO2 Laser Si Reflection Mirror Golden Plated Mirror Dia. 19/20/25/30/38.1mm Thickness 3mm for Laser Cutter Engraver

  • Home
  • KINDLELASER CO2 Laser Si Reflection Mirror Golden Plated Mirror Dia. 19/20/25/30/38.1mm Thickness 3mm for Laser Cutter Engraver

KINDLELASER CO2 Laser Si Reflection Mirror Golden Plated Mirror Dia. 19/20/25/30/38.1mm Thickness 3mm for Laser Cutter Engraver

$13.14$26.79

SKU: 3580094018651 Category:

Description

Product Description

High Reflectivity:>98.9%
(The best high quality with the most reasonable price,under power 30w-200w)

Material
Silicon/Molybdenum
Diameter Tolerance
+0.0/-0.1mm
Thickness Tolerance
±0.1mm
Clear Aperture
>= 90% Diameter
Surface Flatness
lamda/4 at 632.8nm
Bevelling
<0.2×45°

Description
Mateial: Gold-coated Si
Wavelength: 10.6 μm
Diameter Tolerance: +0/-0.13 mm
Thickness Tolerance: ±0.25 mm
FL Tolerance: < ±2%
Centration: < 3 arc minutes
Clear Aperture: > 90%
Surface Figure: < λ/2 per 1 inch diameter
Surface Quality: 40-20 scratch and dig

  • Description

* Mateial: Molybdenum
* Diameter: 15 19.05 20 25 30 38.1mm
* Thickness: 3mm / 5mm
* Pack of 3Pcs
* This optical element is used for planar reflecting the laser beam and is an important component of the laser system.
* Molybdenum mirror is normally polished, without coating, used for tough environments. it has extremely tough surface.

Detailed Images

You have to check the diameter of your old one before purchase the replacement.

Additional information

Model Number

Dia=30mm;Thickness=3mm, Dia=19mm;Thickness=3mm, Dia=38.1mm;Thickness=3mm, Dia=20mm;Thickness=3mm, Dia=25mm;Thickness=3mm
