Description

Brand Name: ACCTEK
Origin: CN(Origin)
Certification: CE
Condition: New
Model Number: AKJ1325F
CNC or Not: CNC
Is Smart Device: No
Product name: cnc fiber laser cutting machine 1000w
Laser power: 1000W / 2000W / 3000W
Working table: Sawtooth Platform
Driving system: Delta servo motor with driver
Transmission: Ball screw tranmission
Power supply: 220V/50HZ 110V/60HZ
Guide rail: Taiwan Hiwin Linear Square Rails
Cooling system: Water Chilller
color: Opitional
Keyword: cnc fiber laser cutting machine 1000w

Hot Sale Cnc Fiber Laser Metal Cutting Machine 1000W Wood Laser Cutter 1325

Product Description

1325 fiber laser cutting machine
Laser source: IPG or Raycus fiber laser source
Fiber laser power : 1000W, 1500W, 2000W, 3000W (Optional)
Working size : 1300*2500mm
X and Y positioning accuracy : +-0.02mm
Transmission mode : X Y axis Gear rack tranmission
Rated voltage and frequency : 220V/50Hz/60Hz/60A

1-Configurations & technical parameter
Working area	1300*2500mm
Control System	Au3tech controller with aut follow system
Laser head	Au3tech brand laser cutting head
Guide rail	Taiwan HIWIN linear guide rail 25mm
Transmission	Taiwan TBI Balls Screw transmission
Electronic Components	French Schneider
Motor	Taiwan Delta 750w servo motor
Max Cutting Speed	35m/min
X axis max speed	65m/min
Y axis max speed	70m/min
Z axis max speed	30m/min
X axis max acceleration	1G
Y axis max acceleration	1G
Cooling Way	Water Cooling
Min line width	0.1mm
Power Requirements	220V, 50/60Hz, 1phase
Continuous Working Time	24Hours
2- Standard parts of the machine
Name	Specification	Quantity
Machine body	1300*2500mm working area	1 set
Laser generator	Standard	1 set
Water chiller	cooling laser head and generator	1 set
Control box	Au3techcontrol system	1 set
Laser cutting head	Auto following function	1 set
Protective lens	standard	1 pc
Focus lens	standard	1 set (2 pcs)
