Description
Product Description
1.The new filter panoramic glass eye protection design: the panoramic filter glass protective cover plays a very good role in protecting your eyes, filtering 97% of the ultraviolet light, you and the people around you do not need to wear goggles, you can also watch laser engraving . Reduce the cost of your goggles and the inconvenience of wearing goggles. 2.Solid and easy installation structure design:The all-aluminum alloy anodized structure design makes the machine more durable, and improves the accuracy of engraving. The entire structure has been designed for quick assembly, and the assembly can generally be completed within 10-20 minutes. 3.Upgraded high-performance fixed-focus laser: no need to adjust the focus before engraving;The focal spot area of the new laser is only 1/3 of the spot area of other ordinary lasers, new laser combine precision engraving and high energy cutting at the same time. The laser power of the fixed-focus laser is more stable than the zoom laser. 4.Wide compatibility:The machine can be compatible with various mature engraving software, such as LaserGRBL, LightBurn, support Win XP / Win 7 / Win 8 / XP / Win 10, and also support MAc system (LightBurn), engraving file format supports NC, BMP, JPG, PNG, DXF etc. 5.Precise scale lines axis:There are precise scale lines on the X-axis and Y-axis to facilitate quick length measurement. 410x400mm large area engraving interval can meet your various engraving needs. 6.Double compression spot coupling technology: laser power is 10-11W, ultra-fine laser focus area is reduced to 0.08*0.15mm, high-density laser can easily cut 15-20mm thick wooden boards and 10-15mm thick black acrylic; it can directly engrave mirror stainless steel Metal, ceramic, glass, engraving & cutting speed is 40% higher than that of ordinary models. 7.Integral screw rod: The machine uses an integrated screw rod instead of a combined coupling. The stepping motor and the screw rod are integrated, which makes the movement of the laser more precise and the coupling more durable. 8.New laser with knob: It is more convenient and quick to adjust the height of the laser. 9. Support offline engraving: A10 PRO configures the terminal control panel, supports offline engraving, you can carry out engraving work anytime and anywhere without being restricted by the computer. 10. The new laser is equipped with a horizontal gyroscope：which stops working immediately when it is tilted to ensure your safety 11. The laser sintering temperature is up to 1200℃ 12. Emergency stop button: Yes 13. Stopper: Yes 14. Reset switch: Yes
15. Expandable engraving size: modular design of the body mechanism, only need to replace the frame components, you can get 410*850mm super large engraving size
|
Item model number
|
ATOMSTACK A10 PRO 50W
|
|
Print Size
|
Recommend Print Size 410*400mm
|
|
Carving Objects
|
All wood, bamboo, paper, plastic, leather, PCB board, aluminum oxide, non-reflective plating and lacquered metal
|
|
Cutting Objects
|
Cardboard, non-woven fabric, light wood, Acrylic material, thin plastic board.
|
|
Laser power
|
50W
|
|
Laser output power
|
10W-11W
|
|
Wave Length
|
445 ± 5nm
|
|
Engraving accuracy
|
0.01mm
|
|
Focusing method
|
fixed focus laser, no need to focus
|
|
Laser protective cover
|
Protect the user’s eyes and prevent pets from grabbing the laser spot.
|
|
Operating software
|
LaserGRBL, LightBurn,
|
|
Support system
|
support Win XP / Win 7 / Win 8 / XP / Win 10 system
|
|
Input Format
|
NC, BMP, JPG, PNG, DXF, etc.
|
|
Data transmission method
|
USB connection
|
|
Input Voltage
|
AC100-240V, 50/60Hz
|
|
Output Voltage
|
DC12V, 5A
|
|
Equipment net weight
|
5kg
|
|
Package weight
|
6.5kg
|
|
Equipment size
|
592*600*270mm
|
|
Packing size
|
618*342*129mm
|
|
Certification
|
CE FCC RoHS
|
Applicable materials
Note
*Do NOT operate laser without eye protection 。
*When the laser engraver is working, the operator should not leave it alone, just in case the materials being carved catch fire。
*Please set up laser engraver in the fireproofing area, with good ventilation。
*Please keep minors (especially kids younger than 14 yours old) away from this laser engraver. Minors of any age should not use this laser without direct Adult supervision and proper eye protection。
*Please do not touch the laser beam with your hands or any other objects you do not wish to engrave/burn/cut. Serious physical harm is possible if used improperly。
