Description
Product Description
Specification
|
Parameters
|
350C(No PC software)
|
350P
|
350M+0.3M integrating sphere
|
|
CCT (K)
|
v
|
v
|
v
|
|
CRI ( R1-R15)
|
v
|
v
|
v
|
|
DUV
|
v
|
v
|
v
|
|
LUX
|
v
|
v
|
v
|
|
mW/m2
|
v
|
v
|
v
|
|
Color/X,Y
|
v
|
v
|
v
|
|
Color/u,v
|
v
|
v
|
v
|
|
Color/U ‘, V’
|
v
|
v
|
v
|
|
Purity
|
v
|
v
|
v
|
|
SDCM
|
v
|
v
|
v
|
|
Ri (i=1 ~ 15)
|
v
|
v
|
v
|
|
S/P Ratio
|
v
|
v
|
v
|
|
CIE1931
|
v
|
v
|
v
|
|
CIE1960
|
v
|
v
|
v
|
|
CIE1976
|
v
|
v
|
v
|
|
SPECTRUM
|
v
|
v
|
v
|
|
Dominant wavelength
|
v
|
v
|
v
|
|
Peak wavelength
|
v
|
v
|
v
|
|
Candlelight E(Fc)
|
v
|
v
|
v
|
|
TM-30
|
|
|
|
|
Luminous flux (Lm)
|
|
|
v
|
|
Radiation flux (W)
|
|
|
v
|
|
Light effect(Lm/w)
|
|
|
v
|
|
Blue light (mW/m2)
|
|
|
v
|
|
Blue light hazard
|
|
|
v
|
|
Flicker
|
|
|
v
|
|
Luminance(Cd/m2)
|
|
|
|
|
PAR,PPFD,YPFD kppfv
|
|
v
|
v
|
|
UVA,UVB,UVC
|
|
|
|
|
Light intensity Cd
|
|
|
|
|
Model
|
OHSP350
|
|
Wavelength range
|
380nm ~780nm
|
|
Light Splitting Mode
|
long focal cross section
|
|
Sensor
|
High precision CCD
|
|
Spectral Bandwidth (FWHM)
|
2nm
|
|
Spectral Resolution
|
0.2nm X, Y repetitive ±0.0005
|
|
Wavelength Accuracy
|
+ 0.5nm
|
|
Illuminantion Accuracy
|
(±4% Reading +1 Digital)
|
|
Lighting Area
|
10mm
|
|
Integrating Time
|
50μs~10000ms
|
|
Chromaticity Coordinate Accuracy
|
±0.0025.
|
|
CCT Range
|
1,000K~ 100,000K
|
|
Stray Light
|
≤0.3%
|
|
Illuminance Range
|
5lx~200klx
|
OHSP350C
OHSP350P
OHSP350M
