Description

CO2 Non-metallic laser marking machine is controlled by the computer, can mark on the surface of processing materials along the desired track through 10.64um laser beam’s beam expanding, focus, galvanometer’s deflection to achieve the engraving effect.

The CO2 laser marker can engrave on all non-metal maeterials like jeans,leateher,plastic,wood,acrylic,papaer….

The non-metallic laser marking machine made by our company has good beam mode, stable system performance, free maintenance, is suitable for the large quantity, multispecies, high speed, high precision and continuous production in the industrial site.



MW-RF series CO2 Laser Marking Engraving Machine Parameter.
Model	MW-RF15	MT-RF30	MT-RF60
Laser Type	Radio frequency CO2 laser generator Imported from U.S.A
Marking Speed	≤8000MM/S
Marking Depth	≤5MM
Repetition Precision	±0.01MM
Cooling Mode	Air Cooling or Water Cooling
Graphic Formats Supported	PLT, DST, AI, DXF, BMP, JPG, CAD, CDR, DWG
Power Source	AC 110/220V±10%, 50/60Hz
Working Temperature	0-40 degree
Working Humidity	5%-85%(No condensation)
Working Environment	Clean, free of dust
Weight	45Kg/ 95kg

1. High speed , equipped with good galvanometer;

2. Small volume ,light weight;

3. Low power, consumption power is less than 500w

4. Completely air cooling ,low energy;

5. No influence of the severe environment and temperature change. If no power, battery and car cigarette lighter can be used for working;

6. Greatly reduce the depreciation cost, satisfying customers' stable large quantity  producing.

7.Engineer door to door service can be supplied accroding to buyers' need.
