Description

Ezcad software synrad coherent davi laser cutting marking machine 20w 30w 60w co2 laser marker cutter for paper wood bamboo

Introduction

1. The CO2 laser generator has high integration, outstanding laser beam and uniform power density. The output laser power is stable. This design greatly improves the anti-reflection ability of the machine through the optical isolator, so that most high-reflectivity materials (such as paper, leather, plastic) can be marked without shadows and virtual opening.

2. Adopt advanced digital high-speed scanning vibrating mirror, fast speed without deviation, small size, good stability, and the performance reaches the international advanced level.

3. Using embedded operating system, performance is ahead of domestic counterparts, good touch interface and powerful control system, can meet the needs of most industry application processes on the market.

Product Description







Sample book



Specification



Type CO2 Laser Marking Machine Power 30w/40w Laser Brand Bostlaser,DAVI Marking Area 110mm*110mm-300*300mm Optional Marking Area 200mm*200mm/150mm*150mm/75mm*75mm Marking Depth ≤0.1mm Marking Speed 7000mm/s Minimum Line Width 0.012mm Minimum Character 0.15mm Repeated Precision ±0.003mm Life-span of Fiber Laser Module 100 000hours Beam Quality M2 <1.5 Focus Spot Diameter <0.01mm Output Power of Laser 10%~100% continuously to be adjusted System Operation Environment Windows XP / W7–32/64bits / W8–32/64bits Cooling Mode Air cooling–Built-in Temperature of Operation Environment 15℃~35℃ Power Input 220V / 50HZ / single phase or 110V / 60HZ / single phase Power Requirement <400W Communication Interface USB Package Dimension 770*410*810mm Gross weight 70kg Optional (Not free of charge) Rotary Device, Moving Table, other customized Automation
