Description

Main Features:

• Highly stable laser output

• High single pulse energy

• High marking efficiency

• Short pulse setup time

• Maintenance free operation

• High reliability

Optical properties

• Average output power: (W): 20

• Central wavelength: (nm): 1064

• Repetition frequency(kHz): 30-60

• Output power stability: <3%

• Red laser: No

Output characteristics

• Output beam diameter(mm): 7±1

• output fiber core diameter (μm): 50 (customizable)

• beam quality(m2):<1.5

• polarization state: random

• Pulse width range(ns): 130-160

• Max single pulse energe(mJ): 0.67

• output fiber length (m): 3(customizable)

Electronic control characteristics

• Input power (V DC ): 24

• power adjustment range (%): 10-100

Other characteristics

• Dimensions (mm ): 215*290*95

• Weight (kg): <10

• Cooling method: air cooling

• Working temperature (℃ ): 0-40

Applications:

• Precision Processing

• Laser Marking

• Graphic engraving of non-metal, gold, silver, copper and aluminum.

• Surface Treatment

• Scientific Research

Package accessoriesare：

• Please refer to package accessoriesare in the packing box.
