Description
Detachable 30W 940nm Fiber Coupled Laser Diode for Printing Plate
- Condition: New
- Warranty: 1 Year, one year
- After-sales Service Provided: Online support
- Spare Parts Type: Fiber coupled diode laser
- Video outgoing-inspection: Provided
- Machinery Test Report: Provided
- Key Selling Points: Easy to Operate
- Showroom Location: Canada, United Kingdom, United States, Italy, France, Germany, Brazil
- Applicable Industries: Garment Shops, Building Material Shops, Manufacturing Plant, Machinery Repair Shops, Farms, Restaurant, Retail, Printing Shops
- Weight (KG): 1 KG
- Wavelength: 940nm
- Keyword: Fiber coupled diode laser
- Power: 30W
- Operating Current: 12A
- Color: Gold
- Function: laser marking
- Working mode: CW
- Fiber Connector: Bare end or SMA
Detachable 30W 940nm Fiber Coupled Laser Diode for Printing Plate
Warranty: one year
Working mode: CW
Fiber core/NA: 105um, 0.22NA
Working mode: CW
Fiber core/NA: 105um, 0.22NA
Application
Medical use
Laser drilling
Remove wrinkles
Skin tightening
Laser cutting
Laser drilling
Remove wrinkles
Skin tightening
Laser cutting
Specification
|
Optional
|
|
|
Center Wavelength λ
|
940nm
|
|
Wavelength Tolerance
|
±10nm
|
|
Output Power
|
30W
|
|
Working Mode
|
CW
|
|
Fiber
|
|
|
Fiber Core
|
105um
|
|
Fiber Connector
|
SMA905 or Bare end
|
|
Fiber Numerical Aperture
|
0.22NA
|
|
Fiber Length
|
1m
|
|
Electrical
|
|
|
Threshold Current Lth
|
1A
|
|
Operating Current Lop
|
12A
|
|
Operating Voltage Vop
|
6V
|
|
Thermal
|
|
|
Operating Temperature
|
15~35℃
|
|
Storage Temperature
|
-20~70℃
|
|
Wavelength Temperature Coefficient
|
0.3nm/℃
|
