Description
Product Description
Features:
Small appearance, easy to carry
Convenient operation
Customized wavelength range and resolution
Fit various applications
Support download for Spectral Analysis 5.0
Applications:
Laser spectral analysis Fluorescence spectral analysis LIBS spectral analysis Absorbance measurement Reflectivity/transmittance measurement Food and agriculture Chemical or biological research Environmental sciences Film thickness measurement
|
Detector
|
||
|
Detector
|
Toshiba TCD1304DG linear CCD array
|
|
|
Wavelength range
|
200-1100nm optional (max.650nm span)
|
|
|
Pixels
|
3648 pixels
|
|
|
Pixel size
|
8um*200um
|
|
|
Spectrometer
|
||
|
Dimensions (mm)
|
89*63.9*36.2
|
|
|
Weight (g)
|
170
|
|
|
Optical resolution
|
<1.0nm
|
|
|
Signal-to-noise ratio
|
300:1 (at full signal)
|
|
|
Dynamic range
|
2*109 (system)
|
|
|
Integration time
|
4ms-10s
|
|
|
Electronics
|
||
|
Power consumption
|
450mA@5VDC
|
|
|
Data transfer speed
|
Full scans into memory every 4 ms with USB 2.0; every 18 ms with USB 1.1
|
|
|
Inputs/outputs
|
5 inputs and 5 outputs (opto-isolator inputs/outputs)
|
|
|
Analog channels
|
One 12 analog input one 12 analog output
|
|
|
Strobe functions
|
Yes
|
|
|
Connector
|
30-pin connector
|
|
