Description
- Brand Name: ACCTEK
- Origin: CN(Origin)
- Certification: CE
- Product name: AK6090F fiber laser marking machine
- Laser source: Raycus Laser Source
- Working area: 600*900mm
- Control system: PC Control System
- Laser Power: 20W 30W 50W 100W
- Laser Source Brand: RAYCUS
- Cooling system: Ari Cooling
- Laser Type: Fiber Laser
- Software: Markingmate 2000
- Laser generator: Raycus
Product Description
AK6090F jewellery marking machinery is specially designed for big work size marking.
Fiber lasere marking machine can mark on metal, steel, aluminum, copper, silver, HDPE, PVC, PE, ceramic and other kinds of materials.
Logo, serial number, code, characters, Qr code…can all be marked with high accuracy.
Details Images
Specification
|
Model
|
AK6090F Fiber laser marking machine
|
|
Laser power
|
20w/30W /50W(optional )
|
|
Laser Wavelength
|
1064±10nm
|
|
Control system
|
PC Control system
|
|
Cooling Mode:
|
Air Cooling,
|
|
Control Software
|
Markingmate2000
|
|
Core Components
|
Laser generator
|
|
Divergence
|
0.3mard
|
|
Marking range
|
600*900mm (Splicing design)
|
|
Marking speed
|
2000 mm/s
|
|
Marking depth
|
0 ~0.5mm
|
|
Engraving line speed
|
≤7000mm/s
|
|
Beam quality
|
1.2~1.8
|
|
Marking Format
|
Graphics, text, bar codes, two-dimensional code, automatically marking the date, batch number, serial number, frequency,etc.
|
|
Graphic format supported
|
bmp,jpg,gif,tga,png,tif,ai,dxf,dst,plt,etc.
|
|
working voltage
|
220V±10%/50/60 Hz ,1 phase
|
|
Unit power
|
<0.5kw
|
|
Use of the environment
|
Clean and dust free or dust less
|
|
Working condition:Humidity
|
5%-75%,free of condensed water
|
|
Laser module life
|
100000 hours
|
|
Gross weight
|
350kg
|
Samples
Applicable Materials:
It is also used in many non-metallic materials marking, such as paper packaging, plastic products, labels, leather fabrics, glass ceramic, resin plastics, wood products, PCB boards, etc.
Packing & Delivery
Package
(1). The machine will be produced after received your deposit.after the machine is ready, we will show you the machine photos and the testing video.then you pay 70% balance payment,we arrange shipping for you.
(2). Anti-collision package edge: All parts of the machine are covered with some soft materials, mainly the use of pearl wool
(3). Fumigation wooden box
(4). Whole film packaging machine
(5). The package is tandard exporrt plywood box,customized for every size machine.
1.Outside package: Standard marine export plywood case .
2.Inner package: Stretch film and plastic film for humidity .
3.We can package according to your requests.
4. Its need about 15-20 days to produce the machine after get your deposit.
Company Profile
Jinan AccTek Machinery Company specializes in manufacturing CNC Router and Laser machines.Since 2005 we have been based in the Industrial Zone of Jinan City, Shandong Province south of Beijing. Our main products are CNC Routers, Laser engraving and cutting machines. Stock or custom configurations are our specialty.
