Description
Feature
★Large LCD screen(128*64 Dots) with saving standard curve function.
☆Imported& Environmental Deuterium lamp,preventing from Ozone inhalation.
☆Adopted high-class grating with wholly hermetic light path design, to ensure the instrument has the super low stray light.
☆Real-time monitoring the lifetime of Deuterium lamp and Tungsten lamp with advanced system.
★Pre-aligned design ensures the user can change lamps conveniently.
☆Wavelength calibration,wavelength setting,change lamp source and dark current calibration automatically.
★With SiO2 coating optical mirror,reducing the pollution from outside fully.
☆Optional PC software to expand the applications to Quantitative, Multi-Wavelength and Kinetics.
☆Widely used for Organic chemistry,Inorganic chemistry,Life sciences, foods, Medicine and health,Agriculture,Geology, Matallurgy and Environment etc Fields.
|
Model
|
TPUV-1000
|
|
Optical System
|
Single beam, Grating 1200 lines/mm
|
|
Wavelength Range
|
200-1020nm
|
|
Bandwidth
|
4nm
|
|
Wavelength Accuracy
|
±1.8nm
|
|
Wavelength Repeatability
|
≤0.2nm
|
|
Photometric Accuracy
|
±0.002A(0-0.5Abs)
±0.004A(0.5-1.0Abs)
±0.4%T(0-100%T)(0.004A,0.5)
|
|
Photometric Repeatability
|
0.001Abs(0-0.5Abs)
0.002Abs(0.5-1.0Abs) ≤±0.2%T(0-100%T) |
|
Photometric Range
|
-0.301-3A,0-200%T
|
|
Stray Light
|
≤0.1%T@360nm;220nm(0.2)
|
|
Stability
|
± 0.001A/h @ 500nm
|
|
Display
|
128*64 Dots LCD
|
|
Detector
|
Silicon Photodiode
|
|
Light Source
|
Tungsten Lamp,Deuterium Lamp
|
|
Output
|
USB Port & Parallel Port(Printer)
|
|
Photometric Mode
|
T,A,C,F
|
