Beelee 9.5mm rotary potentiometer 10V 50V waterproof pcb mount single potentiometer

$32.19

SKU: 3582116018651 Category:

Description


01.Potentiometer is also called variable resistance, sliding resistance and rheostat. It is composed of a resistor body and a rotating or sliding system. A moving contact moves on the resistor body to obtain part of the voltage output.
02.The normal operating temperature range is -10 ~ 70 ℃, and instructions are required for low-temperature operation.




features 9.5mm, single joint with push switch
Rated voltage DC10V,AC50V
Full rotation angle 300°±5°
Slewing life 30000 times
Waterproof grade IP67
