Description
- Item Type: Laser Flashlight
- Brand Name: Q-BAIHE
- Model Number: FU-850LD-1.8-RLD8501
- Threshold current:: 0.8-2mA
- Output power:: 1.2-1.8mW
- Slope efficiency:: 0.35-0.55mW/mA
- Operating voltage:: 1.9V
- Resistance:: 35-65ohm
- Wavelength:: 840-860nm
- Spectral bandwidth:: 0.5nm
- Bean divergence:: 25-30 deg.
- relative intensity noise:: -130 dB/Hz
- Continuous forward current:: 12mA
850nm 1.8mwTwo-leg Optical Communication Laser Diode Laser Tube Near-infrared LD
Features&Applications
1.High speed Datacenter
2.Low dependence of electrical and optical characteristics over temperature
Threshold current:0.8-2mA
Output power:1.2-1.8mW
Slope efficiency:0.35-0.55mW/mA
Operating voltage:1.9V
Resistance:35-65Ω
Wavelength:840-860nm
Spectral bandwidth:0.5nm
Bean divergence:25-30 deg.
relative intensity noise:-130 dB/Hz
Absolute maximum rating：
Storage temperature:-40–100℃
Operating temperature:0-85℃
Continuous forward current:12mA
Soldering temperature:260℃
Chip dimensions：
Chip size:250x230x150μm（t）+-15μm
Bonding pad:μm=100μm
Package:
1x 850nm 1.8mw Laser Diode
