Description

1. Model: LSIPD21-0.3

2. Photosensitive surface diameter: 300um

3. Response wavelength: 800-2100nm

4. Dark current: 8nA@-0.5V

5. Response time: 3ns@-0.5V

6. Package: 4JKFC Can, fiber coupling, optical interface optional

7. Response:

0.7 mA / mW @ 1310 nm 1.0 mA / mW@1600 nm

Application:

1. Industrial automation control 2. Scientific analysis and experiment 3. Simulation of cable television

4. Optical fiber communication 5. Fast optical pulse test 6. Optical time domain reflectometer

7. Optical fiber sensor

Package:
