Circuit control: 12V boost circuit, constant current and constant voltage output

Output specification: Max 3.3a

Scope of application: driving circuit of 445 / 450 / 455nm blue laser module

Size and specification: 65 * 48.5 * 30.5mm (L * w * h)

Frequency control: 0-20khz

Modulation voltage: 0-5V (0V off, 5V on)

Input voltage: 12V (9-14v)

TTL modulation Description: 0-5V voltage signal (0 is off, 5 is on, the frequency determines the speed of laser flash), the positive and negative poles are as follows

The pin descriptions are as follows:
