Description

Nominal resistance range: 100 Ω – 100k Ω

Allowable resistance deviation: ± 5%

Independent linearity: ± 0.25%

Effective electric stroke: ≥ 3600 ° – 10 °

Terminal resistance: ≤ 0.2% R or 5 Ω

Rotation noise: ≤ 3% R or 3 Ω

Insulation resistance: R1 ≥ 1g Ω

Withstand voltage: 101.3pa 710v, 8.5kpa 470v

Environmental characteristics

Rated power (maximum working voltage 315v): + 70 ℃, 2W

Working temperature range: – 55 ℃ – + 125 ℃

Temperature coefficient of resistance: ± 100ppm / ℃

Temperature change: △ R ≤± 2% R, △ (UAB / UAC) ≤± 1%

Collision: 390m / s 24000 times, △ R ≤± 1% R

Vibration: 10-500hz, 0.75mm or 98m / S2, 6h △ R ≤± 1% R, △ (UAB / UAC) ≤± 2%

Climate sequence: △ R ≤± 3% R, R1 ≥ 100m Ω

70 ℃ electrical durability: 2W, 1000h, △ R ≤± 3% R

Mechanical durability: 10000 cycles, △ R ≤± 3% R

Steady state damp heat: △ R ≤± 3% R, R1 ≥ 100m Ω

Physical characteristics

Total mechanical stroke: 3600 °± 10 °

Starting torque: ≤ 36MN · M

Stop torque: ≥ 300MN · M
