Description
- Brand Name: Jolooyo
- Style: Mini
- Model Number: 532ML-80-3350-12V
- Power: 100MW
- Item Type: Stage Lighting Effect
- Occasion: Home Entertainment
- Voltage: 12V
33mm*50mm Adjusted 532nm Green 80mw-100mW Line Positioning Laser Diode Module Focusable 12V Driver TTL
Parameters
wavelength: 532nm
Power: 80mw-100mW
Input voltage: DC 12V
Laser Shape: Line
Focusable: Yes
Modulation: TTL
TTL modulation: 0-20KHz
Divergence angle: <1.2mrad
The circuits control: constant current
Fan Cooling
Operating Characteristics: Long time working
Laser Size: 50 (L) *30 (W) *30 (H)
Case Material: Metal
Finish Color: Black
Warm-up time: None
Operating temperature: 0 ~ 40℃
Storage temperature:-20℃ ~ 40 ℃
Reverse polarity protection: with automatically identify the positive and negative
Power: 80mw-100mW
Input voltage: DC 12V
Laser Shape: Line
Focusable: Yes
Modulation: TTL
TTL modulation: 0-20KHz
Divergence angle: <1.2mrad
The circuits control: constant current
Fan Cooling
Operating Characteristics: Long time working
Laser Size: 50 (L) *30 (W) *30 (H)
Case Material: Metal
Finish Color: Black
Warm-up time: None
Operating temperature: 0 ~ 40℃
Storage temperature:-20℃ ~ 40 ℃
Reverse polarity protection: with automatically identify the positive and negative
Package
1pc 532nm 100mW Laser Line Module
