Description
- Brand Name: IGOLDENCNC
- Origin: CN(Origin)
- Certification: CE
- Condition: New
- Model Number: 3015 1kw fiber laser cutting machine
- CNC or Not: CNC
- Key words: cnc fiber laser cutting machine
- Laser power: 500w 1000w 2000w 6000w
- Servo motor: Servo motor
- Working area (L*W): 3015 fiber laser cutting machine
- Laser Generator: IPG
- Use: fiber laser cutting machine
- Application: cnc fiber laser cutter
- Voltage: Three-phase 380V 50/60Hz
igoldencnc fiber laser cutter 500w 1000w 1500w 2000w 4000w 6000w fiber laser cutting machine sheet metal
|
Model |
3015 fiber laser cutting machine |
|
|
Working area/ Tube length |
3000*1500mm/ 6000mm |
|
|
X axis stroke |
1500mm |
|
|
Y axis stroke |
3000mm |
|
|
Z axis stroke |
300mm |
|
|
Tube diameter |
20-220mm |
|
|
Accuracy |
X, Y axis positioning accuracy |
0.05mm |
|
X, Y axis repositioning accuracy |
0.03mm |
|
|
Speed |
W axis rotate angle |
n*360 |
|
W axis max. ratate speed |
80rpm |
|
|
X, Y axis max. running speed |
150m/min |
|
|
U axis max. positioning speed |
800mm/s |
|
|
X, Y axis max. accelerated speed |
1.5G |
|
|
Power supply |
Phase |
3 |
|
Nominal voltage |
380V |
|
|
Frequency |
50/60Hz |
|
|
Protection grade |
IP65 |
|
|
Machine body |
Max. working loading |
1000kg |
|
Body weight |
2600kg |
|
|
Size(L*W*H) |
8060*3000*1965mm |
|
|
Laser power |
500w/ 750w/ 1000w/ 1500w/ 2000w/ 3000w/ 4000w/ 5000w/ 6000w/ 8000w/ 10000w/ 12000w |
|
|
Worktable optional |
4000*1500mm/ 4000*2000mm/ 6000*2000mm/ 6000*2500mm |
|
|
Tube length optional |
3000mm/ 9000mm |
|
CNC laser cutting machine, also called fiber laser cutting machine, fiber laser cutter, laser cutter, metal laser cutter, metal laser cutting machine, designed for high precision metal plate cutting processing
ot applications is cutting for stainless steel, carbon steel, aluminum, copper, galvanized sheet and other metal plate.
Jinan iGolden CNC Equipment Co., Ltd. has been engaged in laser machine manufacturing for over ten years. All machines are certified by CE and FDA authority, and each of machine undergoes rigorous production assembly and quality inspection process. We are devoted in laser machine manufacturing, which including fiber laser cutting, fiber laser marking, fiber cleaning and fiber laser welding. With advantage technology and research, IGOLDENCNC is becoming more and more popular among various of different counties.
