2pcs/lot RGB Full Color Laser Module 5W Laser Light Laser Diodes TTL Analogue Laser Light DC12V Power Supply

  • Home
  • 2pcs/lot RGB Full Color Laser Module 5W Laser Light Laser Diodes TTL Analogue Laser Light DC12V Power Supply

2pcs/lot RGB Full Color Laser Module 5W Laser Light Laser Diodes TTL Analogue Laser Light DC12V Power Supply

$4,194.00

SKU: 32919621306 Category:

Description

  • Item Type: Stage Lighting Effect
  • Power: 70W
  • Occasion: Professional Stage & DJ
  • Style: DMX Stage Light
  • Brand Name: DYUE
  • Voltage: 12V
  • Model Number: 5WRGB
  • Item Name: RGB Laser Module
  • Wavelenth: R638 G520 B450
  • Output Power: 5W
  • Beam Mode: round spot
  • Beam Divergence : less than 2mrad
  • Lifetime: 10 000 hours
  • Color: Red Green Blue
  • Feature 1: Good stability laser module
  • Feature 2: Low temperature instant start
  • Feature 3: High Brightness laser diodes

2pcs/lot RGB Full Color Laser Module 5W Laser Diodes  TTL Analogue Laser Light  DC12V Power Supply

Main Feature:  New Design Laser Module; High Power Small Size Laser Diodes; High Long life and high stability

Item Name: 5W RGB Laser Module

Wavelength: red 638nm  Green 520nm  Blue 450nm

Outpower:  Red 1.1W  Green 0.9W  Blue 3W

Beam Mode:round spot

Beam Divergence:≤2mrad

Laser  Class:Class 5

Modulation Mode: TTL (Analogue is optional)

Input Stability:±5%

Power Supply:DC12V

Power Consumption:65W

Woking Temperature: -10~40℃

Lifetime: 10,000 hours

Szie: 158X75x87mm

Weight:0.8kg



5W-RGB-LASER-MODULERGB Full Colors Laser ModuleDPSS-Laser-Diodes5W-Laser-Diodes-With-DC12V-Power-Supplyhigh-power-laser-diodes9274623685_8212741159317591760_821274115

Feature:

1. Fine and clear light spot, small divergence angle, good collimation, small size
2. temperature control, drive and laser fully integrated, compact structure, external only DC power supply
3. after high and low temperature storage and vibration shock test, with a reliable stability, the temperature in the range of -10 ~ 40 degrees, can work for 24 hours in a row.
4. Precise scientific heat dissipation design, two-way temperature control and perfect temperature protection function can extend the life of the laser as much as possible

Laser modules are widely used in various fields, such as stage lighting, industrial production, information and communications, medical and cosmetic, decorative lighting, and military. Among them, laser projection, 3D laser printing, laser measuring instrument, laser scale, laser beauty and other products are increasingly welcomed by the market.
