Description
Product Description
Good quality of the laser spot, laser line and laser cross. Stable performance.
Output power: 200mW
Wavelength: 650nm, 655nm, 660nm
Specification
|
Wavelength
|
650nm 655nm 660nm
|
|
Product type
|
dot/line/cross
|
|
Output Power(mW)
|
>200
|
|
Overall dimensions
|
32*32*65mm
|
|
Shell material
|
aluminum
|
|
Wire specifications
|
DC wire
|
|
Supply voltage
|
5V
|
|
Circuit model
|
CW
|
|
Working current
|
5V <350mA
|
|
Circuit control
|
ACC(constant current)
|
|
Wavelength drift(nm/℃)
|
0.25nm
|
|
Divergency angle
|
<0.7mrd collimation, <90°
|
|
Spot size
|
adjustable
|
|
Line width and thickness
|
adjustable
|
|
The lens material
|
Imported glass optical mirror
|
|
Laser level
|
classIIIB
|
|
Working temperature(shell)
|
the low temperature: -10℃, the high temperature: 50℃
|
|
Storage temperature
|
the low temperature: -40℃, the high temperature: 85℃
|
|
Service life
|
10000
|
|
Warranty Time
|
1 year
|
