Description
- Brand Name: LanYuXuan
- Origin: CN(Origin)
- DIY Supplies: ELECTRICAL
- Certification: CE
- Place of Origin: Shanghai, China
- Condition: New
- Warranty: 6 Months
- After-sales Service Provided: Online support
- Spare Parts Type: laser
- Video outgoing-inspection: Provided
- Machinery Test Report: Provided
- Marketing Type: Hot Product 2021
- Brand Name: Crylink
- Key Selling Points: High-accuracy
- Showroom Location: None
- Applicable Industries: Other, Laser
- Weight (KG): 0.05 KG
- Spot size: dia0.18mm
- Laser wavelength: 1535nm
- Working frequency: 10Hz
- Laser Ranging: 3-5km
- Pulse Width: 5ns
- Peak power: 28Kw
- Divergence angle: 12mrad
- Operating temperature: -45~ 65℃
- Overall dimension: 26.5*10.1*8.1mm
- LD Working Voltage: 1.9V
My friend, welcome to our store, if you need other models of this product, please contact me WhatsApp +8615111224853, I will send the product link for you to buy
Description
Wavelength of 1.4-2.0 um is less harmful to the human eye, so a laser with this wavelength range is called the human eye-safe laser. This wavelength range is located in the atmospheric transmission window, the absorption and scattering of the laser is only 1/50 of the 1.06um laser, which is of great significance for long distance action, especially for military applications.
Application area
- Laser ranging
- Laser irradiation
- Laser radar
- Target recognition
- Laser medical treatment
- Optical fiber communication
Feature
- Beam quality near diffraction limit
- Small volume
- Low power consumption
- Good stability
- High reliability
- Wide temperature range
