1245 Focusable 808nm 300mW Infrared IR Line Diode Laser Module with Glass Lens

$53.94

92 in stock

SKU: 32664682412 Category:

Description

  • Brand Name: laserland
  • Certification: NONE
  • Origin: CN(Origin)
Product Description

1245 Focusable 808nm 300mW Infrared IR Line Diode Laser Module with Glass Lens



Feature:

Focusable Lens, easy for user to adjust the focus length by turning aroud the ring at the module tip.

808nm laser line laser



Caution:

Compact Housing with 12mm Diameter and 45mm Length

Please bewear of the heat while the laser module is working. Please keep the module at moderate temperature environment or add a heatsink to let the heat out.





This laser module is an industrial electronic component and used for as Industrial test, Lab, DIY. Not a handheld laser.

Specification
Model  808MD-300-1245
Output Power  300mw
Working Voltage 5.0VDC
Wavelength
808nm
Working Temperature 15-35 ci-degree
Laser Shape line
Divergence <1.5mrad
Focusable Yes
Dimensions ø12mmX45mm
Electronica Pole dc connection
Working Time(under normal operation)   >5000hours
Package 1 pc 808nm laser module



Note:
The modules are tested and the output power are measured by laser power meter before sending out.
Please don’t compare the power of this one with a none-measured laser.
If you doubt the output, please have the laser you received checked by laser power meter.
If there is any problem, please feel free to contact us. We will solve the problem asap.
808nm laser is 99% ir which cannot be seen by human bare eyes.
it has 1% red bomb can be seen.
lens: glass
duty cycle: 45 seconds on, 15 seconds off, if you want to prolong the duty cycle, please add heatsink, here are some we have:

Note:
The modules are tested and the output power are measured by laser power meter before sending out.
Please don’t compare the power of this one with a none-measured laser.
If you doubt the output, please have the laser you recieved checked by laser power meter.
If there is any problem, please feel free to contact us. We will solve the problem asap.

It is IR laser,the laser light cannot be seen by human bare eyes with only using DDC/infrared camera get it.
