10w 20w 30w 50w Fiber Laser Marking Machine 3d Fiber Laser Machine 3 Axis Laser Marking Machine 6090

$20,121.08

SKU: 1005002180420991 Category:

Description

  • Brand Name: ACCTEK
  • Origin: CN(Origin)
  • Certification: CE
  • Condition: New
  • Model Number: AK6090F
  • CNC or Not: CNC
  • Product name: Laser Marking Machine 6090
  • Key words: 3d Fiber Laser Machine
  • MOQ: 1 set
  • Laser Type: Fiber
  • Cooling Mode: Air COOLING
  • Engraving Area: 600mm*900mm
  • Control Software: Markingmate
  • Control system: PC control system
  • Laser type: Fiber laser
  • Graphic Format Supported: AI, PLT, DXF, BMP, Dst, Dwg, LAS, DXP

10w 20w 30w 50w Fiber Laser Marking Machine 3d Fiber Laser Machine 3 Axis Laser Marking Machine 6090

Product Description:

MainFeatures:

1. Long and economic lifetime: We use China best or Germany best laser source, which has a lifetime more than 100,000 hours (more than 10 years).

It does not need consumable parts as like as diode and lamb lasers in short periods . This saves you from service and cost of parts.

2. Low energy consumption: Electro-optic productivity which is the most significant advantages of fiber laser technologies provides you to process with very low energy consumptions.

3. Air-cooling: Energy consumption being low, reduces the heating and cooling needs of the system makes air-cooling possible.

4. Fast Speed: Speed can reach 8000mm/s, which can suitable for various speed big work area marking.

Application:

1. Electronic and communication products, IC products, electric lines, cable computer components and electric appliance.
2. Every kind of precision parts,hardware tools,instrument appliance,aviation and spaceflight appliance.
3. Jewelry, garments, instruments, gifts, office devices, brand scutcheon, sanitary ware appliance.
4. Dishware ,food ,drinking,smoking and alcohol,etc.

Model
Fiber laser marking machine AK6090F
Laser power
20w / 30w / 50w / 100w as options
Divergence
0.3mard
Marking Range
600*900mm
Minimum Line Width
0.01mm
Minimum Character
0.15mm
Marking Depth
0 ~0.5mm
Engraving Line Speed
≤7000mm/s
Repeatability Accuracy
±0.001mm
Beam Quality
M2:1.2~1.8
Marking Format
Graphics, Text, Bar Codes, Two-dimensional Code, Automatically Marking the Date,Batchnumber,Serialnumber, Frequency,etc.
Format Supported
bmp,jpg,gif,tga,png,tif,ai,dxf,dst,plt,etc.
Working Voltage
220V±10%, 50/60Hz, 4A
Unit Power
<0.5kw
Use of the Environment
Clean and Dust Free or Dust less
Working Condition:Humidity
5%-75%,Free of Condensed Water
Laser Module Life
>100000 hours

Details:

Samples:

Aftersale Service :

1.Two-year warranty on the whole machine accessories if the machine parts have any problems,we can change the old machine parts to new ones free.

2.Exceed two years warranty period if the machine parts have any problems,we can offer new machine parts with cost price and you also should pay all the shipping cost.
3.We offer 24 hours technical support by call,email.
4.Our technician can give you remote guide online(Skype/MSN/What's app/viber/Tel/Etc) if you have any question.
5.Machine has been adjusted before delivery,operation disk is included in the delivery.If there is any other questions,pls kindly tell me.
6.We have manual instruction and CD (Guiding Videos) for software Installation,operation and machine's using and maintenance.

About us:

FAQ:
1.I knew nothing about this machine, what kind of machine i should choose?

It is easy to choose. Just tell us what you want to do with cnc router,then let us give you perfect solutions and suggestions.

2: When i got this machine, but i did not know how to use it.What should i do?

We will send video and English manual with the machine.If you still have some doubts, we can talk online with whatsapp ,wechat etc .

3: If some problems happened during warranty period,what should i do?

We will supply free parts in machine warranty period after talking with our service team.We also supply free after-service forever,so any doubts,just us know,we will give you solutions as soon as possible.

4: What is the MOQ?

MOQ for our products is 1 set machine.

If you buy 3 sets one time ,you will have the agent price ,enjoy better price .

5.I am the first time to import the goods,how to do it ?

We are experienced with many years ,this work is not complex ,we can help you.

Contact us:
Name :  Winnie Xu
Mob&Whatsapp: +86-19862191443
Wechat: 13165291807

Skype:export37@acctekgroup.com
E-mail:export37(at)acctekgroup.com
