Description
Products Description
Galvanometer Parameters
|
Speed
|
||||
|
Positioning Speed
|
8000mm/s
|
|||
|
Writing Speed
|
450cps
|
|||
|
Step Response Time(1% of full scale)
|
350us
|
|||
|
Step Response Time(10% of full scale)
|
750us
|
|||
|
Tracking Error Time
|
≤164us
|
|||
|
Precision and Error
|
||||
|
Linearity
|
99.9%
|
|||
|
Repeatability (RMS)
|
＜8μRad
|
|||
|
Gain Error
|
＜5mRad
|
|||
|
Zero Offset
|
＜5mRad
|
|||
|
Long-term Drift Over 8 Hours
|
＜0.5mRad
|
|||
|
Scale Drift
|
＜40PPM/℃
|
|||
|
Zero Drift
|
＜15μRad/℃
|
|||
|
Lens damage threshold
|
||||
|
K9 matrix
|
9.1J/cm^2
|
|||
|
Si matrix
|
10J/cm^2
|
|||
|
Wavelength(3)
|
10600nm/1064nm/355nm or customized
|
|||
|
Power and Signal
|
||||
|
Input Voltage
|
±15VDC
|
|||
|
Rated Current
|
2A
|
|||
|
Interface Signal
|
Digital: XY2-100; Analog: ±5V, ±10V
|
|||
|
Machinery Scan Angle(4)
|
±11°
|
|||
|
Working Current, Temperature, Dimension
|
||||
|
Working Temperature
|
0℃–45℃
|
|||
|
Storage Temperature
|
-10℃–60℃
|
|||
|
Aperture
|
10mm
|
|||
|
Galvanometer Scanner Dimension (LxWxH)
|
118.5×96.5×93.6mm
|
|||
|
Galvanometer Scanner Weight
|
≈1.65Kg
|
|||
