Product Description
The third-generation medium-power single-mode continuous fiber laser ranges from 50W to 1,000W, the new laser has higher electro-optical conversion efficiency (>30%), higher and more stable optical quality, stronger altitude stress-resisting capacity and it applies optimized second-generation fiber transmission system to ensure more stable and more sophisticated cutting effect in thick sheet cutting. This machine applies to many application scenarios: cutting, welding, holing, medical device processing, etc., with a narrow seam of the cut sheet and bright section. Compared with same lasers, it has obvious advantages.

RFL-C1000
|
RFL-C1500x
|
RFL-C2000x
|
RFL-C3000s
|
Average output Power (w)
|
1000
|
1500
|
2000
|
3000
|
Central Wavelength (nm)
|
|
peration Mode
|
cw/Modulated
|
|
sxicur Modulstior frequrncy oruy
|
|
output PowerStability (%)
|
|
Red Laser
|
|
output Connector
|
QBH(customizable)
|
|
Beam Quality (M2)
|
1.3 (25um)
|
|
Polarization State
|
Random
|
|
output FiberLength (m)
|
20 (customizable)
|
|
|
Input Power (V AC)
|
200-240,Single Phase
|
380±10%,Three Phase-Four Wire Connect
|
Control Mode
|
Exterral RS232,Extermal AD, Super Termiral
|
|
Power Adjustment Range(%)
|
|
Dimensions (mm)
|
Exterral RS232,Extermal AD, Super Termiral
|
900*447*521(handle included)
|
Weight (kg)
|
<50
|
|
Cooling Method
|
Water Cooling
|
|
Working Temperature ©
|
|
